Mini Excavators
FR55F-u
  • Operating Weight(kg) 5460
  • Bucket Capacity(m³) 0.18
  • Rated Power(kW) 35.5/2200
FR55F-u
  • Features
  • Parameter
  • Video
  • Inquiry
  • Related Products
Engine
Features
Engine

Kubota Engine V2607-CR-E5, imported from Japan, boasts robust performance, high reliability, low noise, and better fuel efficiency.

Main Pump

Linde main pump features large displacement and high efficiency; manufactured by Weichai, which belongs to the same group as Lovol, it has strong independent service capabilities.

Main Valve

Linde main valve ensures precise distribution - it allocates appropriate flow according to load demands; Lovol's exclusively customized main control valve spool allows for more precise micro-manipulation.

Item Unit Parameter
Operating Weight kg 5460
Bucket Capacity 0.18
Rated Power kW 35.5/2200
Emissions - EU Stage V
Transportation Dimensions(L*W*H) mm 5490*1960*2550
Max.Digging Radius mm 6105
Max.Digging Height mm 5670
Max.Digging Depth mm 3630
Max.Unloading Height mm 4000
Bucket Digging Force kN 40
Stick Digging Force kN 30
Track Width mm 400
