FOPs & ROPs cab, one-button start, new intelligent instrument panel, multi-directional adjustable seat for ergonomic functionality, cup holder, phone box, headrest, three-way opening covers. Both operation and maintenance are very convenient and comfortable.
Kubota Engine, imported hydraulic components; Boom and arm equipped with anti-burst valves; Internal hydraulic piping; Safety-certified cab; Cast steel structure for boom side shift and boom front fork rear seat, overall reliability and durability.
Large displacement main pump and travel motor, high-torque cycloidal swing motor, large bucket capacity, significantly enhancing work efficiency.
Tailless, side swing arm, telescopic chassis, split cab, foldable dozer blade, quick-coupling device for various attachments, switchable single/double-direction breaker lines, all highlighting the machine's flexibility.
Item | Unit | Parameter |
Operating Weight | kg | 1810 |
Bucket Capacity | m³ | 0.04 |
Rated Power | kW | 11.4 |
Emissions | - | EU Stage V |
Transportation Dimensions(L*W*H) | mm | 3575*990*2347 |
Max.Digging Radius | mm | 3905 |
Max.Digging Height | mm | 3540 |
Max.Digging Depth | mm | 2310 |
Max.Unloading Height | mm | 2440 |
Bucket Digging Force | kN | 15.2 |
Stick Digging Force | kN | 8.5 |
Track Width | mm | 230 |
