Weichai Hydraulic Powertrain delivers optimal engine-hydraulic system integration.
15% higher overall operational efficiency and over 20% improved fuel efficiency versus previous D-Series models.
WP4.1 engine with a service life of up to 30,000 hours.
Weichai Hydraulic System validated through 20+ years of field performance.
IP67-rated waterproof connectors ensure maximum machine reliability.
Extended boom (4600mm) and lengthened arm (2500mm).
Standard quick coupler and log grapple.
Forest-specific protections:
Boom cylinder guard and side-mounted arm piping to prevent tree abrasion damage.
Operator safety cabin with full protective covering.
Reinforced chassis with side impact beams, roller guards, tow hitch, and thickened underplates.
| Item | Unit | Parameter |
| Operating Weight | kg | 16200 |
| Bucket Capacity | m³ | / |
| Rated Power | kW | 92 |
| Emissions | - | WEICHAI WP4.1 |
| Transportation Dimensions(L*W*H) | mm | 8120*3010*3275 |
| Max.Digging Radius | mm | / |
| Max.Digging Height | mm | 7960 |
| Max.Digging Depth | mm | 5200 |
| Max.Unloading Height | mm | 5570 |
| Bucket Digging Force | kN | / |
| Stick Digging Force | kN | / |
| Track Width | mm | 960 |
