WP10 Weichai National III engine with dedicated fuel map; ZF automatic transmission, FNR + left handle control; Constant variable work-steering amplification hydraulic system; The three systems perfectly matched for higher efficiency and lower fuel consumption.
Extended wheelbase of 3350mm, new counterweight, Lovol's patented composite articulation, honeycomb bushings, brake dryer, higher reliability, better suited for heavy loads.
Newly designed cab and seats, fully automatic transmission, adjustable steering wheel, LCD display, LED lights, more comfortable driving experience.
Three-door engine hood for easy maintenance.
Item | Unit | Parameter |
Rated Load | kg | 5500 |
Operating Weight | kg | 17980 |
Bucket Capacity | m³ | 3.3 |
Emissions | - | Stage III |
Wheel Base | mm | 3350 |
Engine Power | kW | 162 |
Dimensions(L*W*H) | mm | 8850X2980X3420 |
Unloading Height | mm | 3100 |
Unloading Distance | mm | 1130 |
Total Cycle Time | s | 10 |
Min.Turning Radius | mm | 7140 |
Max.Travel Speed | km/h | 42 |
