WEICHAI possesses the only National Key Laboratory for Internal Combustion Engine Reliability among internal com-bustion engine enterprises.
The fuel tank has been upgrad-ed to a PXE plastic fuel tank, which is manufactured using an integrated rotational molding process. It has a large capacity, robust structure, high reliability, and high cleanliness.
The main valve body is made of vermicular graphite cast iron material, which has better shock absorption and thermal conduc-tivity. Small shrinkage tendency to avoid spool jamming.
Withstood 3 million cycles of ultra-high pressure endurance testing without cracking, ensur-ing reliable quality.
· Standard equipment includes a 1.2 cubic meter earthmover bucket.
· The large-capacity earthmoving bucket is specialized and optimized for less cutting resistance and a 25% increase in wear resistance.
· Key areas are made of high-strength plates and wear-resistant plates, with bucket teeth and seats made of wear-resistant materials to extend service life.
| Item | Unit | Parameter |
| Operating Weight | kg | 24000 |
| Bucket Capacity | m³ | 1.2 |
| Rated Power | kW | 160 |
| Emissions | - | Stage III |
| Transportation Dimensions(L*W*H) | mm | |
| Max.Digging Radius | mm | 9845 |
| Max.Digging Height | mm | 9915 |
| Max.Digging Depth | mm | 6630 |
| Max.Unloading Height | mm | 7140 |
| Bucket Digging Force | kN | 133 |
| Stick Digging Force | kN | 106 |
| Track Width | mm |
