Weichai H platform engine with a lifespan of up to 30,000 hours; Heavy-duty swing platform reducing stress by more than 40%. Chassis uses a split design specialized for mining, with a newly upgraded work device structure, lifespan exceeding 15,000 hours.
Utilizing Weichai Linde powertrain technology; Independent water and oil cooling system for better energy efficiency; 5.5 cubic meter new bucket with high capacity and wear resistance, overall work efficiency improved by 15% compared to competitors, fuel efficiency increased by more than 20%.
Newly upgraded cab with sealed front and top windows; Newly developed Lovol's intelligent operation system enables, automatic recognition of working conditions, auxiliary operation, and personalized customization.
Engine maintenance interval of 500 hours, newly designed maintenance channel, tool box with added electric grease gun, easier maintenance.
Item | Unit | Parameter |
Operating Weight | kg | 80100 |
Bucket Capacity | m³ | 5.5(standard bucket) |
Rated Power | kW | 566/1900 |
Emissions | - | Stage IV |
Transportation Dimensions(L*W*H) | mm | 12780*4380*4840 |
Max.Digging Radius | mm | 11970 |
Max.Digging Height | mm | 11950 |
Max.Digging Depth | mm | 7410 |
Max.Unloading Height | mm | 7190 |
Bucket Digging Force | kN | 406 |
Stick Digging Force | kN | 368 |
Track Width | mm | 650 |
