The self-developed drive system has been widely proven in the market and has good durability. Provides high traction when combined with specialised engines
The openable side guard offers a spacious area and the reasonable layout of filter elements and hydraulic components facilitate convenient maintenance. The hexahedral cab is designed with ergonomic considerations and provides a spacious interior and wide field of view.
The machine is equipped with a straight tilt blade for enhanced cutting force. It offers the option of incorporating a three-tooth ripper to showcase its remarkable adaptability to diverse challenging conditions such as clay, hardened frozen soil, and more.
| Item | Unit | Parameter |
| Overall weight | kg | 23450 |
| Engine brand | - | Cummins NT855-C280S10/Weichai WP12G240E306 |
| Rated power/rated speed | kW/rpm | 175/1800 |
| Machine external dimensions | mm | 6060*4200*3402 |
| Track center distance | mm | 2000 |
| Track shoe width | mm | 560/610/660 |
| Ground contact length | mm | 2430 |
| Fuel tank capacity | L | 450 |
| Blade type | - | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade |
| Blade capacity | m³ | 4.6 |
| Emissions | Indicated as per international standards | Eu stageⅡ |
